Suporte e manutenção de hardware Nutanix Dell PowerEdge



O hardware Nutanix que você tem em sua infraestrutura de TI ainda podem fornecer a funcionalidade, flexibilidade e praticidade para a grande maioria das organizações hoje. A capacidade de adicionar memória adicional (se ainda não especificada no momento da compra) e CPU fornece aos clientes uma variedade de opções para atualizar seus servidores host (ambientes virtualizados) para continuar fornecendo o desempenho necessário após as datas de fim de vida dos fabricantes. Essas opções de atualização em potencial significam que os clientes não precisam buscar constantemente novas soluções de servidor ao final de um programa interno de ciclo de vida de 3 ou 5 anos devido aos servidores não serem mais adequados para o propósito.



Hardware Nutanix de parceiros

Tercerizando a manutenção do hardware Nutanix



A DC Parts fornece às organizações uma opção alternativa viável e sustentável para estender a vida útil de seus hardware Nutanix após os anúncios de ‘fim da vida’ ou ‘fim da vida útil do suporte’, sendo capaz de fornecer opções de atualização de hardware recomendadas, que inclui e incorpora a instalação completa e trabalho de configuração realizado por engenheiros de campo técnicos experientes. Nossa capacidade de continuar fornecendo um serviço de suporte de manutenção de servidor alternativo para haedware Nutanix auxilia ainda mais as organizações, oferecendo uma solução econômica para hardware Nutanix de missão crítica. Essa solução reduz significativamente seu custo total de propriedade e também gera um retorno maior de suas despesas de capital inicial com hardware de servidor de TI.

A DC Parts oferece uma abordagem flexível para organizações que buscam se integrar parcial ou totalmente aos serviços de manutenção e suporte de sua organização para sistemas de servidor atuais ou históricos. Esses níveis de serviço variam de NBD (Próximo Dia Útil) a uma resposta de 24 horas por dia, 7 dias por semana. Nossos serviços de manutenção e suporte variam de apenas peças a suporte por telefone e remoto. Nossas páginas de nível de serviço descrevem esses e outros serviços em detalhes.

Entre em contato conosco para ver se podemos fornecer as garantias de que você precisa, principalmente para explorar um serviço de suporte de manutenção alternativo.

Valor residual do ativo para o seu hardware Nutanix



Nosso serviço de manutenção e suporte exclusivo para hardware Nutanix pode fornecer a você o potencial de customizar um contrato de manutenção de custo neutro para hardware Nutanix que agora é pós-garantia, fim da vida útil ou fim da vida útil (EOL / EOSL). Nosso serviço permite que os clientes com hardware Nutanix tenha vários estágios em um programa de ciclo de vida, ao passo que forneçendo suporte de manutenção estendido, independentemente da necessidade de 3,6,9 ou mesmo 12 meses de suporte, assim criando efetivamente uma solução neutra em termos de custo.



Diminuição de custo no seu contrato



Permitimos que uma solução de manutenção de custo neutro seja fornecida por meio do valor residual em seu hardware Nutanix que removeríamos no final do prazo de suporte de manutenção acordado. Bem como os serviços para desativação segura e eliminação de dados de acordo com os requisitos de conformidade internos também farão parte da discussão do programa de serviços de ciclo de vida de hardware.

Se você não precisa de um serviço de suporte, nosso serviço de manunteção ainda pode beneficiá-lo. Assim sendo podemos fornecer uma cotação de valor residual para seu servidor de TI e hardware de armazenamento e discutir o processo de desativação e eliminação de dados, permitindo que você obtenha um retorno muito maior sobre seu investimento de capital inicial. Não há obrigação de obter uma cotação da DC Parts, mas permite que você explore se este serviço pode ser viável e benéfico para você.

Infraestrutura hiperconvergente (HCI) está se tornando uma plataforma de serviços significativa no datacenter, e com boa razão. Processamento de abstração, armazenamento e recursos de rede para criar uma rede totalmente definida por software datacenter é a progressão lógica da década de tendência de virtualização. Empresas como a Nutanix estão liderando o caminho, permitindo que os departamentos de TI criem e expandam ambientes de aplicativos através da simples adição de servidores de prateleira comuns. Eliminando a despesa e complexidade de implantação e gerenciamento de um datacenter cheio de dispositivos díspares com uma mistura de gerenciamento interfaces mais múltiplas redes e armazenamento os protocolos tornam mais fácil implantar e oferecer suporte a uma nuvem no local.

Como um dos principais fornecedores de servidores corporativos, a linha de produtos Dell EMC é uma reconhecida padrão quando se trata de implantações de datacenter. A plataforma PowerEdge é um bloco de construção ideal para uma nuvem privada Nutanix. Parceria da Dell EMC com Nutanix se estende aos dispositivos da série XC – um e dois servidores PowerEdge de unidade de rack certificados especificamente para suporte a solução Nutanix HCI.

A DC Parts possui um grande conhecimento do hardware Dell PowerEdge e nossa equipe tem anos de experiência com sistemas PowerEdge. A DC Parts pode personalizar um pacote de suporte para atender às necessidades imediatas ou de longo prazo de sua organização, desde contratos de 9 a 5 de curto prazo até pacotes de manutenção anual 24 horas por dia, 7 dias por semana. Os consultores da DC Parts trabalham com os clientes para garantir que eles obtenham as garantias de que precisam a um custo adequado ao seu orçamento. Nossa flexibilidade, junto com nosso entendimento abrangente da linha PowerEdge, permite que a DC Parts ajude as organizações a maximizar o investimento em sua infraestrutura de TI.



Benefícios do suporte de manutenção da DC Parts em hardware Nutanix com Dell PowerEdge



  • Diagnóstico técnico e reparo de servidores Dell PowerEdge
  • Engenheiro de nível 3 atribuído a uma conta
  • Disponibilidade de serviço global
  • Suporte de manutenção para equipamentos Dell atuais e em fim de vida
  • Datas de suporte pró-rata e co-rescisão
  • Auditorias / pesquisas de site
  • Migração de dados / plataforma
  • Descomissionamento de TI
  • Apagamento de dados
  • Engenheiros técnicos de campo altamente experientes e especialmente treinados
  • Cache de peças sobressalentes no local
  • Vários métodos para gerar um tíquete de chamada de falha
  • Assistência de helpdesk
  • Recomendações de firmware e sistema operacional
  • Serviços profissionais
    • Consultoria
    • VMware
    • Atualizações de hardware
  • Contratos de suporte de manutenção flexíveis de curto e longo prazo
  • Aluguel de hardware
  • DMR (retenção de mídia digital)
  • Economia operacional



Fim do suporte da Nutanix com hardware Dell PowerEdge, mas não da DC Parts



Supported Models

R440 8SFF Hardware Compatibility

Qualification date: March 2020

Component Description SKU
Chassis 2.5″ Chassis with up to 8 Hot Plug Hard Drives

Nodes per chassis: 1

Use cases:

  • Analytics and Big Data
  • Remote Office/Branch Office
  • End-User Computing/Virtual Desktop Infrastructure
321-BCUV
Boot Drive 1 x BOSS controller card + with 2 M.2 Sticks 240G(RAID 1),LP 403-BBPZ
Power Supply 1 x Dual, Hot Plug, Redundant Power Supply (1+1), 550W 450-AGOY
Embedded Systems Management iDRAC9 Basic 385-BBLD
iDRAC Password iDRAC, Factory Generated Password 379-BCSF



Component Description SKU
Storage: All-Flash Only SAS SSDs
2, 4, 6, or 8 x 2.5″ SAS SSDs
960 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV 400-ASFI
960GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW 400-BDSI
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256 TBW 400-BEPD
1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive, 400-BDSU
Dell 1.92TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug Drive PM883 400-BCVC
1.92TB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW 400-BCOM
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW 400-BEQI
1.92TB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, Toshiba PM5 400-BCMJ
1.92TB SSD SATA RI (1 DWPD), 512e, 6Gbps, 2.5″, ISE, Samsung, PM883a, PE/PV 345-BBHN
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD,7008 TBW 400-BDNK
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW 400-AYZI
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW 400-BBQX
7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW 345-BBBP
Storage Controller 1 x Storage Controller
HBA330 Controller Adapter, Low Profile 405-AANK
HBA330 12Gbps SAS HBA Controller (NON-RAID), MiniCard 405-AAJW
RAID Option No RAID 780-BCDI



Table. Cascade Lake and Cascade Lake Refresh: CPU and Memory
Component Description SKU
CPU 2 x Any Intel Cascade Lake or Cascade Lake Refresh CPU (Silver, Gold, or Platinum, with 8 or more cores per CPU). Various
Memory
DDR4-2666, 1.2V, 16 GB, RDIMM

  • 16 x 16 GB = 256 GB
370-ADND
DDR4-2666, 1.2V, 32 GB, RDIMM

  • 16 x 32 GB = 512 GB
370-ADNF



Table. Networking
Component Description SKU
PcIe Network Interface 1 x Intel X710 Dual Port 10GbE SFP+ Adapter, PCIe Low Profile 555-BCKN





R640 10 SFF Hardware Compatibility



Qualification date (321-BCQL): January 2018

Qualification date (321-BCQQ): October 2018

Component Description SKU
Chassis Use cases:

  • Analytics and Big Data
  • Remote Office/Branch Office
  • End-User Computing/Virtual Desktop Infrastructure
PowerEdge R640 Server

Nodes per chassis: 1

210-AKWU
2.5 Chassis with up to 10 Hard Drives and 3PCIe slots

Nodes per chassis: 1

321-BCQL
2.5″ Chassis with up to 10 Hard Drives, 8 NVMe Drives and 3PCIe Slots, 2CPU only

Nodes per chassis: 1

321-BCQQ
Boot Drive 1 x M.2 SSD
BOSS controller card + with 2 M.2 Sticks 120G(RAID 1),LP 403-BBPM
BOSS controller card + with 2 M.2 Sticks 240G(RAID 1),LP 403-BBPZ
BOSS controller card + with 2 M.2 Sticks 240G (RAID 1),LP 403-BCHI
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),LP 403-BBUU
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),LP 403-BCHH
Power Supply 1 x Dual, Hot-plug power supply
750W Dual, Hot-plug, Redundant Power Supply (1 + 1) 450-ADWS
Dual, Hot-plug, Redundant Power Supply (1+1), 1100W 450-ADWM
Embedded Systems Management iDRAC9 Enterprise, Integrated Dell Remote Access Controller, Enterprise 385-BBKT
iDRAC Password iDRAC, Legacy Password 379-BCSG



Table. Storage
Component Description SKU
Storage: All-Flash Only SATA/SAS SSDs
2, 4, 6, 8, or 10 x 2.5″ SATA/SAS SSDs

480 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ARXG  (EOS)
480 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV 400-ASEO  (EOS)
480GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive 400-BDSD  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQG  (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW 400-AZHC  (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW 400-AZII  (EOS)
960 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ASFO  (EOS)
960 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV 400-ASFI
960 GB SSD SATA Mix Use 6Gbps 512e 2.5in Hot-plug Drive, S4600, 3 DWPD, 5256 TBW 400-ASYL  (EOS)
960GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW 400-BDSI
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256 TBW 400-BEPD
1.92 TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ASGE  (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV,3 DWPD,10512 TBW 400-ASFZ
1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive, 400-BDSU
Dell 1.92TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug Drive PM883 400-BCVC
1.92TB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW 400-BCOM
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW 400-BEQI
1.92TB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, Toshiba PM5 400-BCMJ
1.92TB SSD SATA RI (1 DWPD), 512e, 6Gbps, 2.5″, ISE, Samsung, PM883a, PE/PV 345-BBHN
3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a,1 DWPD,7008 TBW 400-ASGI
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW 400-AYZI
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD,7008 TBW 400-BDNK
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW 400-BBQX
7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW 345-BBBP
Storage: All-Flash Only SATA/SAS and NVMe SSDs
6 or 8 x 2.5″ SATA/SAS SSDs

480 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ARXG  (EOS)
480 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV 400-ASEO  (EOS)
480GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive 400-BDSD  (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW 400-AZHC  (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW 400-AZII  (EOS)
960 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ASFO  (EOS)
960 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV 400-ASFI
960GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW 400-BDSI
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256 TBW 400-BEPD
1.92 TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ASGE  (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV,3 DWPD,10512 TBW 400-ASFZ
1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive, 400-BDSU
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW 400-BEQI
1.92TB SSD SATA RI (1 DWPD), 512e, 6Gbps, 2.5″, ISE, Samsung, PM883a, PE/PV 345-BBHN
3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a,1 DWPD,7008 TBW 400-ASGI
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW 400-AYZI
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD,7008 TBW 400-BDNK
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW 400-BBQX
7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW 345-BBBP
2 or 4 x 2.5″ NVMe SSDs
Dell 800GB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725a with Carrier 400-AUMO  (EOS)
Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725a with Carrier 400-AUMP  (EOS)
Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, P4610 with Carrier 400-BELT
Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725b with Carrier 400-BEFC
Dell 3.2TB NVMe Mix Use Express Flash 2.5in SFF Drive U.2 P4610 400-BEDQ
Dell 6.4TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, P4610 with Carrier 400-BELR
Storage: Hybrid Mix of SATA/SAS SSDs and HDDs
2 x 2.5″ SATA/SAS SSDs

480 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ARXG  (EOS)
480 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV 400-ASEO  (EOS)
480GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive 400-BDSD  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQG  (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW 400-AZHC  (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW 400-AZII  (EOS)
960 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ASFO  (EOS)
960 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV 400-ASFI
960GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW 400-BDSI
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256 TBW 400-BEPD
1.92 TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ASGE  (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV,3 DWPD,10512 TBW 400-ASFZ
1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive, 400-BDSU
Dell 1.92TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug Drive PM883 400-BCVC
1.92TB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW 400-BCOM
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW 400-BEQI
1.92TB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, Toshiba PM5 400-BCMJ
1.92TB SSD SATA RI (1 DWPD), 512e, 6Gbps, 2.5″, ISE, Samsung, PM883a, PE/PV 345-BBHN
3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a,1 DWPD,7008 TBW 400-ASGI
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW 400-AYZI
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD,7008 TBW 400-BDNK
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW 400-BBQX
7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW 345-BBBP
4, 6, or 8 x 2.5″ HDDs
1 TB 7.2K RPM Near-Line SAS 12Gbps 512n 2.5in Hot-plug Hard Drive 400-ASHE
1.2TB 10K RPM SAS 12Gbps 512n 2.5in Hot-plug Hard Drive 400-ASHI
1.2TB 10K RPM Self-Encrypting SAS 12Gbps 512n 2.5in Hot-plug Hard Drive, FIPS140 400-ASHK
1.8TB 10K RPM SAS 12Gbps 512e 2.5in Hot-plug Hard Drive 400-ARXC
2 TB 7.2K RPM Near-Line SAS 12Gbps 512n 2.5in Hot-plug Hard Drive 400-ASHP
2.4TB 10K RPM SAS 12Gbps 512e 2.5in Hot-plug Hard Drive 400-AVEZ
2.4TB 10K RPM Self-Encrypting SAS 12Gbps 512e 2.5in Hot-plug Hard Drive, FIPS140 400-AVHH
Storage Controller 1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard 405-AAJU
RAID Option No RAID 780-BCDI



Table. Skylake: CPU and Memory
Component Description SKU
CPU 2 x Any Intel Skylake Silver, Gold, or Platinum CPU (8 or more cores per CPU). Various
Memory
DDR4-2666, 1.2V, 16 GB, RDIMM

  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
370-ADND
DDR4-2666, 1.2V, 32 GB, RDIMM

  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
370-ADNF
DDR4-2666, 1.2V, 64 GB, LRDIMM

  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
370-ADNH
DDR4-2667, 1.2V, 128 GB, LRDIMM

  • 12 x 128 GB = 1.5 TB
  • 16 x 128 GB = 2 TB
  • 24 x 128 GB = 3 TB
370-ADMX



Table. Cascade Lake and Cascade Lake Refresh: CPU and Memory
Component Description SKU
CPU 2 x Any Intel Cascade Lake or Cascade Lake Refresh CPU (Silver, Gold, or Platinum, with 8 or more cores per CPU). Various
Memory
DDR4-3200, 1.2V, 8 GB, RDIMM

  • 12 x 8 GB = 96 GB
  • 16 x 8 GB = 128 GB
  • 24 x 8 GB = 192 GB
370-AEVO
DDR4-2933, 1.2V, 16 GB, RDIMM

  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
370-AEQF
DDR4-3200, 1.2V, 16 GB, RDIMM

  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
370-AEVQ
DDR4-2933, 1.2V, 32 GB, RDIMM

  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
370-AEQH
DDR4-3200, 1.2V, 32 GB, RDIMM

  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
370-AEVN
DDR4-2933, 1.2V, 64 GB, RDIMM

  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
370-AEQD
DDR4-3200, 1.2V, 64 GB, RDIMM

  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
370-AEVP
DDR4-2667, 1.2V, 128 GB, LRDIMM

  • 12 x 128 GB = 1.5 TB
  • 16 x 128 GB = 2 TB
  • 24 x 128 GB = 3 TB
370-ADMX



Table. Networking
Component Description SKU
FlexibleLOM Adapter 1 x Flexible LAN on Motherboard (FLOM) adapter
Mellanox ConnectX-4 LX Dual Port 10/25GbE SFP28, rNDC 406-BBLG
Intel X550 Quad Port 10GbE BASE-T, rNDC 540-BBUY
Intel X550 Dual Port 10GbE BASE-T & i350 Dual Port 1GbE BASE-T, rNDC 540-BBUZ
Intel Ethernet I350 QP 1Gb Network Daughter Card 540-BBCB
Broadcom 57416 Dual Port 10GbE BASE-T & 5720 Dual Port 1GbE BASE-T, rNDC 540-BBUK
Broadcom 57414 Dual Port 10/25GbE SFP28, rNDC 540-BBUM
Intel X710 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE, rNDC 555-BCKO
PCIe Network Interface 1 x PCIe Network Interface
Mellanox ConnectX-4 LX Dual Port 10/25GbE SFP28 Adapter, PCIe Low Profile 406-BBLD
Intel X550 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile 540-BBRL
Intel XXV710 Dual Port 25GbE SFP28 PCIe Adapter, Low Profile, Customer Install 540-BCCN
Intel Ethernet i350 Quad Port 1GbE BASE-T Adapter, PCIe Low Profile 540-BBCZ
Broadcom 57414 Dual Port 10/25GbE SFP28 Adapter, PCIe Low Profile 540-BBVK
Intel Ethernet I350 Dual Port 1GbE BASE-T Adapter, PCIe Low Profile 540-BBDB
Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile 540-BBVJ
Intel XXV710 Dual Port 10/25GbE SFP28 Adapter, PCIe Low Profile 540-BCCM
Broadcom 57412 Dual Port 10GbE SFP+ Adapter, PCIe Low Profile 540-BBVI
Mellanox ConnectX-5 Dual Port 10/25GbE SFP28 Adapter, PCIe Low Profile 540-BCMQ
Broadcom 57412 Dual Port 10GbE SFP+ & 5720 Dual Port 1GbE BASE-T rNDC 540-BBUL
Intel X710 Dual Port 10GbE SFP+ Adapter, PCIe Low Profile 555-BCKN
Dual NIC Configuration

R640 4 LFF Hardware Compatibility



Qualification date: March 2018



Component Description SKU
Chassis Use cases: Remote Office/Branch Office

PowerEdge R640 Server

Nodes per chassis: 1

210-AKWU
3.5 Chassis with up to 4 Hard Drives and 3PCIe slots

Nodes per chassis: 1

321-BCQF
Boot Drive 1 x M.2 SSD
BOSS controller card + with 2 M.2 Sticks 120G(RAID 1),LP 403-BBPM
BOSS controller card + with 2 M.2 Sticks 240G(RAID 1),LP 403-BBPZ
BOSS controller card + with 2 M.2 Sticks 240G (RAID 1),LP 403-BCHI
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),LP 403-BBUU
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),LP 403-BCHH
Power Supply 2 x Hot-plug power supply
750W Dual, Hot-plug, Redundant Power Supply (1 + 1) 450-ADWS
Dual, Hot-plug, Redundant Power Supply (1+1), 1100W 450-ADWM
Embedded Systems Management iDRAC9 Enterprise, Integrated Dell Remote Access Controller, Enterprise 385-BBKT
iDRAC Password iDRAC, Legacy Password 379-BCSG



Table. Storage
Component Description SKU
Storage: All-Flash Only SATA/SAS SSDs
2 or 4 x 3.5″ SATA/SAS SSDs

480 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, 3.5in HYB CARR, SM863a 400-ASES  (EOS)
480 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASEP  (EOS)
480GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSV  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQG  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQD  (EOS)
800GB SSD SAS MU 12Gbps 512e 2.5in HP Drive,3.5in HYB CARR, PM1645, 3 DWPD, 4380 TBW 400-AZFZ  (EOS)
960 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a 400-ASFP  (EOS)
960 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASFJ  (EOS)
960 GB SSD SATA Mix Use 6Gbps 512e 2.5in Hot-plug Drive, 3.5in HYB CARR, S4600, 3 DWPD, 5256 TBW 400-ASYM  (EOS)
960GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSW
960GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 5256 TBW 400-BCQF
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive, PM5-V,3 DWPD, 5256 TBW 400-BEQD
1.92 TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a 400-ASGF  (EOS)
1.92 TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASGB  (EOS)
1.92TB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSY
1.92TB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW 400-BCOM
1.92TB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 10512 TBW 400-BCPF
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3 DWPD 10512 TBW 400-BEPQ
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3 DWPD 10512 TBW 400-BEQT
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in HP Drive,3.5in HYB CARR, PM1643, 1 DWPD, 7008 TBW 400-AYYB
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug,3.5in HYB CARR S4510 Drive, 1 DWPD,7008 TBW 400-BDMN
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-R HYB CARR Drive, 1 DWPD, 7008 TBW 400-BBQU
7.68TB Solid State Drive RI SAS 12Gbps 512e 2.5in PM1643a w/ 3.5in HYB CARR 1 DWPD 14016 TBW 345-BBCH
Storage: Hybrid Mix of SATA/SAS SSDs and HDDs
2 x 3.5″ SATA/SAS SSDs

480 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, 3.5in HYB CARR, SM863a 400-ASES  (EOS)
480 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASEP  (EOS)
480GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSV  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQG  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQD  (EOS)
800GB SSD SAS MU 12Gbps 512e 2.5in HP Drive,3.5in HYB CARR, PM1645, 3 DWPD, 4380 TBW 400-AZFZ  (EOS)
960 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a 400-ASFP  (EOS)
960 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASFJ  (EOS)
960GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSW
960GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 5256 TBW 400-BCQF
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive, PM5-V,3 DWPD, 5256 TBW 400-BEQD
1.92 TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a 400-ASGF  (EOS)
1.92 TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASGB  (EOS)
1.92TB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSY
1.92TB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW 400-BCOM
1.92TB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 10512 TBW 400-BCPF
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3 DWPD 10512 TBW 400-BEPQ
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3 DWPD 10512 TBW 400-BEQT
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in HP Drive,3.5in HYB CARR, PM1643, 1 DWPD, 7008 TBW 400-AYYB
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug,3.5in HYB CARR S4510 Drive, 1 DWPD,7008 TBW 400-BDMN
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-R HYB CARR Drive, 1 DWPD, 7008 TBW 400-BBQU
7.68TB Solid State Drive RI SAS 12Gbps 512e 2.5in PM1643a w/ 3.5in HYB CARR 1 DWPD 14016 TBW 345-BBCH
2 x 3.5″ HDDs
1TB 7.2K RPM NLSAS 12Gbps 512n 2.5in Hot-plug Hard Drive, 3.5in HYB CARR 400-ASKF
2TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-Plug Hard Drive 400-ASHS
4TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-plug Hard Drive 400-ASHY
8TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive 400-ASIB
8TB 7.2K RPM Self-Encrypting NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive, FIPS140 400-ASID
8 TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot- plug Hard Drive 400-ASUG
12TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive 400-AWIP
12TB 7.2K RPM Self-Encrypting NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive, FIPS140 400-AXLN
12TB 7.2K SAS 12Gbps 512e 3.5in Hot-Plug Hard Drive 400-BEJR
Storage Controller 1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard 405-AAJU
RAID Option No RAID 780-BCDI



Table. Skylake: CPU and Memory
Component Description SKU
CPU 1 x Any Intel Skylake Silver, Gold, or Platinum CPU (8 or more cores per CPU). Various
Memory DDR4-2666, 1.2V, 16 GB, RDIMM

  • 6 x 16 GB = 96 GB
  • 12 x 16 GB = 192 GB
370-ADND
DDR4-2666, 1.2V, 32 GB, RDIMM

  • 6 x 32 GB = 192 GB
  • 12 x 32 GB = 384 GB
370-ADNF
DDR4-2666, 1.2V, 64 GB, LRDIMM

  • 6 x 64 GB = 384 GB
  • 12 x 64 GB = 768 GB
370-ADNH
DDR4-2667, 1.2V, 128 GB, LRDIMM

  • 6 x 128 GB = 768 GB
  • 12 x 128 GB = 1.5 TB
370-ADMX



Table. Cascade Lake and Cascade Lake Refresh: CPU and Memory
Component Description SKU
CPU 1 x Any Intel Cascade Lake or Cascade Lake Refresh CPU (Silver, Gold, or Platinum, with 8 or more cores per CPU). Various
Memory DDR4-3200, 1.2V, 8 GB, RDIMM

  • 6 x 8 GB = 48 GB
  • 12 x 8 GB = 96 GB
370-AEVO
DDR4-2933, 1.2V, 16 GB, RDIMM

  • 6 x 16 GB = 96 GB
  • 12 x 16 GB = 192 GB
370-AEQF
DDR4-3200, 1.2V, 16 GB, RDIMM

  • 6 x 16 GB = 96 GB
  • 12 x 16 GB = 192 GB
370-AEVQ
DDR4-2933, 1.2V, 32 GB, RDIMM

  • 6 x 32 GB = 192 GB
  • 12 x 32 GB = 384 GB
370-AEQH
DDR4-3200, 1.2V, 32 GB, RDIMM

  • 6 x 32 GB = 192 GB
  • 12 x 32 GB = 384 GB
370-AEVN
DDR4-2933, 1.2V, 64 GB, RDIMM

  • 6 x 64 GB = 384 GB
  • 12 x 64 GB = 768 GB
370-AEQD
DDR4-3200, 1.2V, 64 GB, RDIMM

  • 6 x 64 GB = 384 GB
  • 12 x 64 GB = 768 GB
370-AEVP
DDR4-2667, 1.2V, 128 GB, LRDIMM

  • 6 x 128 GB = 768 GB
  • 12 x 128 GB = 1.5 TB
370-ADMX



Table. Networking
Component Description SKU
FlexibleLOM Adapter 1 x Flexible LAN on Motherboard (FLOM) adapter
Mellanox ConnectX-4 LX Dual Port 10/25GbE SFP28, rNDC 406-BBLG
Intel X550 Quad Port 10GbE BASE-T, rNDC 540-BBUY
Intel X550 Dual Port 10GbE BASE-T & i350 Dual Port 1GbE BASE-T, rNDC 540-BBUZ
Intel Ethernet I350 QP 1Gb Network Daughter Card 540-BBCB
Broadcom 57416 Dual Port 10GbE BASE-T & 5720 Dual Port 1GbE BASE-T, rNDC 540-BBUK
Broadcom 57414 Dual Port 10/25GbE SFP28, rNDC 540-BBUM
Intel X710 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE, rNDC 555-BCKO
PCIe Network Interface 1 x PCIe Network Interface
Mellanox ConnectX-4 LX Dual Port 10/25GbE SFP28 Adapter, PCIe Low Profile 406-BBLD
Intel X550 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile 540-BBRL
Intel XXV710 Dual Port 25GbE SFP28 PCIe Adapter, Full Height, Customer Install 540-BCDG
Intel Ethernet i350 Quad Port 1GbE BASE-T Adapter, PCIe Low Profile 540-BBCZ
Broadcom 57414 Dual Port 10/25GbE SFP28 Adapter, PCIe Low Profile 540-BBVK
Intel Ethernet I350 Dual Port 1GbE BASE-T Adapter, PCIe Low Profile 540-BBDB
Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Low Profile 540-BBVJ
Intel XXV710 Dual Port 10/25GbE SFP28 Adapter, PCIe Low Profile 540-BCCM
Broadcom 57412 Dual Port 10GbE SFP+ Adapter, PCIe Low Profile 540-BBVI
Mellanox ConnectX-5 Dual Port 10/25GbE SFP28 Adapter, PCIe Low Profile 540-BCMQ
Broadcom 57412 Dual Port 10GbE SFP+ & 5720 Dual Port 1GbE BASE-T rNDC 540-BBUL
Intel X710 Dual Port 10GbE SFP+ Adapter, PCIe Low Profile 555-BCKN
Dual NIC Configuration

R740xd 12 LFF Hardware Compatibility



Qualification date: January 2018



Component Description SKU
Chassis Use cases:

  • Analytics and Big Data
  • Backup and Disaster Recovery
  • Files and Objects
  • Private Cloud
  • Test and Development
  • End-User Computing/Virtual Desktop Infrastructure
PowerEdge R740xd Server

Nodes per chassis: 1

210-AKZR
Chassis with Up to 12 x 3.5 Hard Drives for 2CPU Configuration

Nodes per chassis: 1

321-BCPU
Boot Drive 1 x M.2 SSD
BOSS controller card + with 2 M.2 Sticks 120G(RAID 1),FH 403-BBPJ
BOSS controller card + with 2 M.2 Sticks 240G(RAID 1),FH 403-BBPT
BOSS controller card + with 2 M.2 Sticks 240G (RAID 1),FH 403-BCHP
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),FH 403-BBSV
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),FH 403-BCHJ
Power Supply 2 x Hot-plug power supply
750W Dual, Hot-plug, Redundant Power Supply (1 + 1) 450-ADWS
Dual, Hot-plug, Redundant Power Supply (1+1), 1100W 450-ADWM
Dual, Hot-plug, Redundant Power Supply (1+1), 1600W, 250 Volt Power Cord Required for Use 450-AFMQ
Embedded Systems Management iDRAC9 Enterprise, Integrated Dell Remote Access Controller, Enterprise 385-BBKT
iDRAC Password iDRAC, Legacy Password 379-BCSG



Table. Storage
Component Description SKU
Storage: All-Flash Only SATA/SAS SSDs
4, 6, 8, 10, or 12 x 3.5″ SATA/SAS SSDs

480 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, 3.5in HYB CARR, SM863a 400-ASES  (EOS)
480 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASEP  (EOS)
480GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSV  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQG  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQD  (EOS)
800GB SSD SAS MU 12Gbps 512e 2.5in HP Drive,3.5in HYB CARR, PM1645, 3 DWPD, 4380 TBW 400-AZFZ  (EOS)
960 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a 400-ASFP  (EOS)
960 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASFJ  (EOS)
960 GB SSD SATA Mix Use 6Gbps 512e 2.5in Hot-plug Drive, 3.5in HYB CARR, S4600, 3 DWPD, 5256 TBW 400-ASYM  (EOS)
960GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSW
960GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 5256 TBW 400-BCQF
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive, PM5-V,3 DWPD, 5256 TBW 400-BEQD
1.92 TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a 400-ASGF  (EOS)
1.92 TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASGB  (EOS)
1.92TB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSY
1.92TB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW 400-BCOM
1.92TB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 10512 TBW 400-BCPF
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3 DWPD 10512 TBW 400-BEPQ
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3 DWPD 10512 TBW 400-BEQT
3.84 TB SSD SAS RI 12Gbps 512e 2.5in Hot-plug Drive, 3.5in HYB CARR, PM1633a 400-ASGK  (EOS)
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in HP Drive,3.5in HYB CARR, PM1643, 1 DWPD, 7008 TBW 400-AYYB
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug,3.5in HYB CARR S4510 Drive, 1 DWPD,7008 TBW 400-BDMN
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-R HYB CARR Drive, 1 DWPD, 7008 TBW 400-BBQU
7.68TB Solid State Drive RI SAS 12Gbps 512e 2.5in PM1643a w/ 3.5in HYB CARR 1 DWPD 14016 TBW 345-BBCH
Storage: Hybrid Mix of SATA/SAS SSDs and HDDs
2 or 4 x 3.5″ SATA/SAS SSDs

480 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, 3.5in HYB CARR, SM863a 400-ASES  (EOS)
480 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASEP  (EOS)
480GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSV  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQG  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQD  (EOS)
800GB SSD SAS MU 12Gbps 512e 2.5in HP Drive,3.5in HYB CARR, PM1645, 3 DWPD, 4380 TBW 400-AZFZ  (EOS)
960 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a 400-ASFP  (EOS)
960 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASFJ  (EOS)
960GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSW
960GB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 5256 TBW 400-BCQF
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive, PM5-V,3 DWPD, 5256 TBW 400-BEQD
1.92 TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863a 400-ASGF  (EOS)
1.92 TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, 3.5in HYB CARR, PX05SV 400-ASGB  (EOS)
1.92TB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot plug, 3.5in HYB CARR S4610 Drive 400-BDSY
1.92TB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW 400-BCOM
1.92TB SSD SAS Mixed use 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-V Drive, 3 DWPD, 10512 TBW 400-BCPF
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3 DWPD 10512 TBW 400-BEPQ
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in with 3.5in HYB CARR Drive,PM5-V,3 DWPD 10512 TBW 400-BEQT
3.84 TB SSD SAS RI 12Gbps 512e 2.5in Hot-plug Drive, 3.5in HYB CARR, PM1633a 400-ASGK  (EOS)
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in HP Drive,3.5in HYB CARR, PM1643, 1 DWPD, 7008 TBW 400-AYYB
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug,3.5in HYB CARR S4510 Drive, 1 DWPD,7008 TBW 400-BDMN
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in with 3.5in HYB CARR PM5-R HYB CARR Drive, 1 DWPD, 7008 TBW 400-BBQU
7.68TB Solid State Drive RI SAS 12Gbps 512e 2.5in PM1643a w/ 3.5in HYB CARR 1 DWPD 14016 TBW 345-BBCH
4, 6, 8, or 10 x 3.5″ HDDs

1TB 7.2K RPM NLSAS 12Gbps 512n 2.5in Hot-plug Hard Drive, 3.5in HYB CARR 400-ASKF
2TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-Plug Hard Drive 400-ASHS
2.4TB 10000rpm Sas-12gbps 512e 256mb Buffer 2.5inch (in 3.5inch Hybrid Carrier) 400-ANTE
4TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-plug Hard Drive 400-ASHY
4TB 7.2K RPM Self-Encrypting NLSAS 12Gbps 512n 3.5in Hot-plug Hard Drive, FIPS140 400-ASHZ
8TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive 400-ASIB
8TB 7.2K RPM Self-Encrypting NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive, FIPS140 400-ASID
8 TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot- plug Hard Drive 400-ASUG
12TB 7.2K RPM Self-Encrypting NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive, FIPS140 400-AXLN
12TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive 400-AWIP
12TB 7.2K SAS 12Gbps 512e 3.5in Hot-Plug Hard Drive 400-BEJR
Storage Controller 1 x Storage Controller
HBA330 Controller Adapter, Low Profile 405-AANK
HBA330 12Gbps SAS HBA Controller (NON-RAID), MiniCard 405-AAJW
RAID Option No RAID 780-BCDI



Table. Skylake: CPU and Memory
Component Description SKU
CPU 2 x Any Intel Skylake Silver, Gold, or Platinum CPU (8 or more cores per CPU). Various
Memory DDR4-2666, 1.2V, 16 GB, RDIMM

  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
370-ADND
DDR4-2666, 1.2V, 32 GB, RDIMM

  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
370-ADNF
DDR4-2666, 1.2V, 64 GB, LRDIMM

  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
370-ADNH
DDR4-2667, 1.2V, 128 GB, LRDIMM

  • 12 x 128 GB = 1.5 TB
  • 16 x 128 GB = 2 TB
  • 24 x 128 GB = 3 TB
370-ADMX



Table. Cascade Lake and Cascade Lake Refresh: CPU and Memory
Component Description SKU
CPU 2 x Any Intel Cascade Lake or Cascade Lake Refresh CPU (Silver, Gold, or Platinum, with 8 or more cores per CPU). Various
Memory DDR4-3200, 1.2V, 8 GB, RDIMM

  • 12 x 8 GB = 96 GB
  • 16 x 8 GB = 128 GB
  • 24 x 8 GB = 192 GB
370-AEVO
DDR4-2933, 1.2V, 16 GB, RDIMM

  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
370-AEQF
DDR4-3200, 1.2V, 16 GB, RDIMM

  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
370-AEVQ
DDR4-2933, 1.2V, 32 GB, RDIMM

  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
370-AEQH
DDR4-3200, 1.2V, 32 GB, RDIMM

  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
370-AEVN
DDR4-2933, 1.2V, 64 GB, RDIMM

  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
370-AEQD
DDR4-3200, 1.2V, 64 GB, RDIMM

  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
370-AEVP
DDR4-2667, 1.2V, 128 GB, LRDIMM

  • 12 x 128 GB = 1.5 TB
  • 16 x 128 GB = 2 TB
  • 24 x 128 GB = 3 TB
370-ADMX



Table. Networking
Component Description SKU
FlexibleLOM Adapter 1 x Flexible LAN on Motherboard (FLOM) adapter
Mellanox ConnectX-4 LX Dual Port 10/25GbE SFP28, rNDC 406-BBLG
Intel X550 Quad Port 10GbE BASE-T, rNDC 540-BBUY
Intel X550 Dual Port 10GbE BASE-T & i350 Dual Port 1GbE BASE-T, rNDC 540-BBUZ
Intel Ethernet I350 QP 1Gb Network Daughter Card 540-BBDD
Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC 540-BBBB
Broadcom 57416 Dual Port 10GbE BASE-T & 5720 Dual Port 1GbE BASE-T, rNDC 540-BBUK
Broadcom 57414 Dual Port 10/25GbE SFP28, rNDC 540-BBUM
Intel Ethernet I350 QP 1Gb Network Daughter Card 540-BBCB
Intel X710 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE, rNDC 555-BCKO
PCIe Network Interface 1 x PCIe Network Interface
Mellanox ConnectX-4 LX Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height 406-BBLE
Intel X550 Dual Port 10GbE BASE-T Adapter, PCIe Full Height 540-BBRO
Intel X710 Dual Port 10GbE Direct Attach SFP+ Adapter, PCIe Full Height 540-BBHP
Intel XXV710 Dual Port 25GbE SFP28 PCIe Adapter, Full Height, Customer Install 540-BCDG
Intel Ethernet I350 Dual Port 1GbE BASE-T Adapter, PCIe Full Height 540-BBDH
Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Full Height 540-BBUI
Broadcom 57412 Dual Port 10GbE SFP+ Adapter, PCIe Full Height 540-BBUH
Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height 540-BBCT
Intel XXV710 Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height 540-BCDH
Mellanox ConnectX-5 Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height 540-BCNM
Mellanox ConnectX-5 EX Dual Port 40/100GbE QSFP28 Adapter, PCIe Full Height 540-BCIU
Broadcom 57414 Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height 540-BBUJ
Dual NIC Configuration

R740xd 24 SFF Hardware Compatibility



Qualification date (321-BCPY): January 2018

Qualification date (321-BDHZ): January 2018

Qualification date (321-BCRC): October 2018



Component Description SKU
Chassis Use cases:

  • Analytics and Big Data
  • Database and Business Critical Apps
  • Private Cloud
  • Test and Development
  • End-User Computing/Virtual Desktop Infrastructure
PowerEdge R740xd Server

Nodes per chassis: 1

210-AKZR
Chassis with Up to 24 x 2.5″ Hard Drives for 2CPU

Nodes per chassis: 1

321-BCPY
Chassis with Up to 24 x 2.5 Hard Drives for 2CPU, GPU Capable Configuration

Nodes per chassis: 1

321-BDHZ
Chassis up to 24 x 2.5 Hard Drives including 12 NVME Drives, 2CPU Configuration

Nodes per chassis: 1

321-BCRC
Boot Drive 1 x M.2 SSD
BOSS controller card + with 2 M.2 Sticks 120G(RAID 1),FH 403-BBPJ
BOSS controller card + with 2 M.2 Sticks 240G(RAID 1),FH 403-BBPT
BOSS controller card + with 2 M.2 Sticks 240G (RAID 1),FH 403-BCHP
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),FH 403-BBSV
BOSS controller card + with 2 M.2 Sticks 480GB (RAID 1),FH 403-BCHJ
Power Supply 2 x Hot-plug power supply
750W Dual, Hot-plug, Redundant Power Supply (1 + 1) 450-ADWS
Dual, Hot-plug, Redundant Power Supply (1+1), 1100W 450-ADWM
Dual,Hot-plug Power Supply , 2400W,250 Volt Power Cord Required for Use 450-AGFO
Dual, Hot-plug, Redundant Power Supply (1+1), 1600W, 250 Volt Power Cord Required for Use 450-AFMQ
Embedded Systems Management iDRAC9 Enterprise, Integrated Dell Remote Access Controller, Enterprise 385-BBKT
iDRAC Password iDRAC, Legacy Password 379-BCSG



Table. Storage
Component Description SKU
Storage: All-Flash Only SATA/SAS SSDs
8, 10, 12, 14, 16, 18, 20, 22, or 24 x 2.5″ SATA/SAS SSDs

480 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ARXG  (EOS)
480 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV 400-ASEO  (EOS)
480GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive 400-BDSD  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQG  (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW 400-AZHC  (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW 400-AZII  (EOS)
960 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ASFO  (EOS)
960 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV 400-ASFI
960 GB SSD SATA Mix Use 6Gbps 512e 2.5in Hot-plug Drive, S4600, 3 DWPD, 5256 TBW 400-ASYL  (EOS)
960GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW 400-BDSI
960GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 5256 TBW 400-BCQN
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256 TBW 400-BEPD
1.92 TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ASGE  (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV,3 DWPD,10512 TBW 400-ASFZ
1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive, 400-BDSU
Dell 1.92TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug Drive PM883 400-BCVC
1.92TB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW 400-BCOM
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW 400-BEQI
1.92TB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, Toshiba PM5 400-BCMJ
1.92TB SSD SATA RI (1 DWPD), 512e, 6Gbps, 2.5″, ISE, Samsung, PM883a, PE/PV 345-BBHN
3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a,1 DWPD,7008 TBW 400-ASGI
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW 400-AYZI
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD,7008 TBW 400-BDNK
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW 400-BBQX
7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW 345-BBBP
Storage: All-Flash Only SATA/SAS and NVMe SSDs
20 x 2.5″ SATA/SAS SSDs

480 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ARXG  (EOS)
480 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV 400-ASEO  (EOS)
480GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive 400-BDSD  (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW 400-AZHC  (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW 400-AZII  (EOS)
960 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ASFO  (EOS)
960 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV 400-ASFI
960 GB SSD SATA Mix Use 6Gbps 512e 2.5in Hot-plug Drive, S4600, 3 DWPD, 5256 TBW 400-ASYL  (EOS)
960GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW 400-BDSI
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256 TBW 400-BEPD
1.92 TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ASGE  (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV,3 DWPD,10512 TBW 400-ASFZ
1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive, 400-BDSU
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW 400-BEQI
1.92TB SSD SATA RI (1 DWPD), 512e, 6Gbps, 2.5″, ISE, Samsung, PM883a, PE/PV 345-BBHN
3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a,1 DWPD,7008 TBW 400-ASGI
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW 400-AYZI
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD,7008 TBW 400-BDNK
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW 400-BBQX
7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW 345-BBBP
4 x NVMe SSDs
Dell 800GB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725a with Carrier 400-AUMO  (EOS)
Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725a with Carrier 400-AUMP  (EOS)
Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, P4610 with Carrier 400-BELT
Dell 1.6TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, PM1725b with Carrier 400-BEFC
Dell 3.2TB NVMe Mix Use Express Flash 2.5in SFF Drive U.2 P4610 400-BEDQ
Dell 6.4TB, NVMe, Mixed Use Express Flash, 2.5 SFF Drive, U.2, P4610 with Carrier 400-BELR
Storage: Hybrid Mix of SATA/SAS SSDs and HDDs
4, 6, or 8 x 2.5″ SATA/SAS SSDs

480 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ARXG  (EOS)
480 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV 400-ASEO  (EOS)
480GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive 400-BDSD  (EOS)
480GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 2628 TBW 400-BCQG  (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645, 3 DWPD, 4380 TBW 400-AZHC  (EOS)
800GB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, PM1645A, 3 DWPD, 4380 TBW 400-AZII  (EOS)
960 GB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ASFO  (EOS)
960 GB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV 400-ASFI
960GB SSD SATA Mixed Use 6Gbps 512e 2.5in Hot Plug S4610 Drive, 3 DWPD, 5256 TBW 400-BDSI
960GB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 5256 TBW 400-BCQN
960GB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V,3 DWPD, 5256 TBW 400-BEPD
1.92 TB Solid State Drive SATA Mix Use 6Gbps 512n 2.5in Hot-plug Drive, 3X DWPD, SM863a 400-ASGE  (EOS)
1.92TB SSD SAS Mix Use 12Gbps 512n 2.5in Hot-plug Drive, PX05SV,3 DWPD,10512 TBW 400-ASFZ
1.92TB SSD SATA Mix used 6Gbps 512e 2.5in Hot Plug S4610 Drive, 400-BDSU
Dell 1.92TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot-plug Drive PM883 400-BCVC
1.92TB SSD SAS Mixed use 12Gbps 512e 2.5in Hot-Plug PM5-V Drive, 3 DWPD, 10512 TBW 400-BCOM
1.92TB SSD SAS Mixed Use 12Gbps FIPS-140 512e 2.5in, PM5-V, 3 DWPD, 10512 TBW 400-BEQI
1.92TB SSD SAS Mix Use 12Gbps 512e 2.5in Hot-plug Drive, Toshiba PM5 400-BCMJ
1.92TB SSD SATA RI (1 DWPD), 512e, 6Gbps, 2.5″, ISE, Samsung, PM883a, PE/PV 345-BBHN
3.84TB SSD SAS Read Intensive 12Gb 512e 2.5in Hot-plug Drive, PM1633a,1 DWPD,7008 TBW 400-ASGI
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in Hot-plug Drive, PM1643, 1 DWPD, 7008 TBW 400-AYZI
3.84TB SSD SATA Read Intensive 6Gbps 512e 2.5in Hot Plug S4510 Drive, 1 DWPD,7008 TBW 400-BDNK
3.84TB SSD SAS Read Intensive 12Gbps 512e 2.5in PM5-R Hot-plug Drive, 1 DWPD, 7008 TBW 400-BBQX
7.68TB Solid State Drive Read Intensive SAS 12Gbps 512e 2.5in PM1643a Hot-Plug 1 DWPD 14016 TBW 345-BBBP
8, 10, 12, 14, 16, 18, or 20 x 2.5″ HDDs

1 TB 7.2K RPM Near-Line SAS 12Gbps 512n 2.5in Hot-plug Hard Drive 400-ASHE
1.2TB 10K RPM Self-Encrypting SAS 12Gbps 512n 2.5in Hot-plug Hard Drive, FIPS140 400-ASHK
1.8TB 10K RPM SAS 12Gbps 512e 2.5in Hot-plug Hard Drive 400-ARXC
2 TB 7.2K RPM Near-Line SAS 12Gbps 512n 2.5in Hot-plug Hard Drive 400-ASHP
2.4TB 10K RPM SAS 12Gbps 512e 2.5in Hot-plug Hard Drive 400-AVEZ
2.4TB 10K RPM Self-Encrypting SAS 12Gbps 512e 2.5in Hot-plug Hard Drive, FIPS140 400-AVHH
Storage Controller 1 x Storage Controller
HBA330 Controller Adapter, Low Profile 405-AANK
HBA330 12Gbps SAS HBA Controller (NON-RAID), MiniCard 405-AAJW
RAID Option No RAID 780-BCDI



Table. Skylake: CPU and Memory
Component Description SKU
CPU 2 x Any Intel Skylake Silver, Gold, or Platinum CPU (8 or more cores per CPU). Various
Memory DDR4-2666, 1.2V, 16 GB, RDIMM

  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
370-ADND
DDR4-2666, 1.2V, 32 GB, RDIMM

  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
370-ADNF
DDR4-2666, 1.2V, 64 GB, LRDIMM

  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
370-ADNH
DDR4-2667, 1.2V, 128 GB, LRDIMM

  • 12 x 128 GB = 1.5 TB
  • 16 x 128 GB = 2 TB
  • 24 x 128 GB = 3 TB
370-ADMX



Table. Cascade Lake and Cascade Lake Refresh: CPU and Memory
Component Description SKU
CPU 2 x Any Intel Cascade Lake or Cascade Lake Refresh CPU (Silver, Gold, or Platinum, with 8 or more cores per CPU). Various
Memory DDR4-3200, 1.2V, 8 GB, RDIMM

  • 12 x 8 GB = 96 GB
  • 16 x 8 GB = 128 GB
  • 24 x 8 GB = 192 GB
370-AEVO
DDR4-2933, 1.2V, 16 GB, RDIMM

  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
370-AEQF
DDR4-3200, 1.2V, 16 GB, RDIMM

  • 12 x 16 GB = 192 GB
  • 16 x 16 GB = 256 GB
  • 24 x 16 GB = 384 GB
370-AEVQ
DDR4-2933, 1.2V, 32 GB, RDIMM

  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
370-AEQH
DDR4-3200, 1.2V, 32 GB, RDIMM

  • 12 x 32 GB = 384 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
370-AEVN
DDR4-2933, 1.2V, 64 GB, RDIMM

  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
370-AEQD
DDR4-3200, 1.2V, 64 GB, RDIMM

  • 12 x 64 GB = 768 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
370-AEVP
DDR4-2667, 1.2V, 128 GB, LRDIMM

  • 12 x 128 GB = 1.5 TB
  • 16 x 128 GB = 2 TB
  • 24 x 128 GB = 3 TB
370-ADMX



Table. Networking
Component Description SKU
FlexibleLOM Adapter 1 x Flexible LAN on Motherboard (FLOM) adapter
Mellanox ConnectX-4 LX Dual Port 10/25GbE SFP28, rNDC 406-BBLG
Intel X550 Quad Port 10GbE BASE-T, rNDC 540-BBUY
Intel X550 Dual Port 10GbE BASE-T & i350 Dual Port 1GbE BASE-T, rNDC 540-BBUZ
Intel Ethernet I350 QP 1Gb Network Daughter Card 540-BBDD
Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC 540-BBBB
Broadcom 57416 Dual Port 10GbE BASE-T & 5720 Dual Port 1GbE BASE-T, rNDC 540-BBUK
Broadcom 57414 Dual Port 10/25GbE SFP28, rNDC 540-BBUM
Intel Ethernet I350 QP 1Gb Network Daughter Card 540-BBCB
Intel X710 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE, rNDC 555-BCKO
PCIe Network Interface 1 x PCIe Network Interface
Mellanox ConnectX-4 LX Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height 406-BBLE
Intel X550 Dual Port 10GbE BASE-T Adapter, PCIe Full Height 540-BBRO
Intel X710 Dual Port 10GbE Direct Attach SFP+ Adapter, PCIe Full Height 540-BBHP
Intel XXV710 Dual Port 25GbE SFP28 PCIe Adapter, Low Profile, Customer Install 540-BCCN
Intel Ethernet I350 Dual Port 1GbE BASE-T Adapter, PCIe Full Height 540-BBDH
Broadcom 57416 Dual Port 10GbE BASE-T Adapter, PCIe Full Height 540-BBUI
Broadcom 57412 Dual Port 10GbE SFP+ Adapter, PCIe Full Height 540-BBUH
Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height 540-BBCT
Intel XXV710 Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height 540-BCDH
Mellanox ConnectX-5 Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height 540-BCNM
Mellanox ConnectX-5 EX Dual Port 40/100GbE QSFP28 Adapter, PCIe Full Height 540-BCIU
Broadcom 57414 Dual Port 10/25GbE SFP28 Adapter, PCIe Full Height 540-BBUJ
Dual NIC Configuration



Table. GPU
Component Description SKU
GPU 1 or 2 x GPU

NVIDIA Tesla M10 GPU, Requires GRID 2.0 SW for VDI Function 489-BBCG
NVIDIA Tesla P40 24GB GPU (Single/Dual GPU) 489-BBCN
Dell 16GB NVIDIA Tesla T4 GPU Graphic Card 490-BEYM
NVIDIA® Tesla™ V100 32GB, Passive, Double Wide, Full Height GPU 490-BENY
NVIDIA Tesla V100S 32GB, 250W, Passive, Double Wide, Full Height GPU 490-BFRR
NVIDIA® Tesla™ V100 16GB, Passive, Double Wide, Full Height GPU 490-BEDZ
NVIDIA Quadro RTX 6000 24 GB, 250W, Dual Slot, PCIe x16 Passive Cooled, Full Height GPU 490-BFRQ
NVIDIA Quadro RTX 8000 48 GB, 250W, Dual Slot,PCIe x16 Passive Cooled, Full Height GPU 490-BFSG

R630 10 SFF Hardware Compatibility



Qualification date: July 2017



Component Description SKU
Chassis Use cases:

  • Analytics and Big Data
  • Remote Office/Branch Office
  • End-User Computing/Virtual Desktop Infrastructure
PowerEdge R630 Server

Nodes per chassis: 1

210-ACXS
1 RU Chassis with up to 10, 2.5″ Hard Drives, 3 PCIe Slots

Nodes per chassis: 1

321-BBKM
Boot Drive 1 x 64 GB Solid State SATA-DOM Boot Drive

400-AOQL
Power Supply 2 x Hot-plug power supplyDual, Hot-plug, Redundant Power Supply (1+1), 1100W 450-ADWM
Embedded Systems Management iDRAC8 Enterprise, Integrated Dell Remote Access Controller, Enterprise 385-BBHO



Table. Storage
Component Description SKU
Storage: Hybrid Mix of SATA SSDs and HDDs
2 x 2.5″ SATA SSDs
480 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMID
800 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 400-AIFQ
960 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMHE
1.6 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 400-AIGF
1.92 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMHH
4, 6, or 8 x 2.5″ HDDs
1 TB 7.2K RPM Near-Line SAS 2.5in Hot-plug Hard Drive 400-ALUN
2 TB 7.2K RPM NLSAS 512n 2.5in Hot-plug Hard Drive 400-AMUC
Storage: All-Flash Only SATA/SAS SSDs
2 or 10 x 2.5″ SATA/SAS SSDs
480 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMID
800 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 400-AIFQ
960 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMHE
1.6 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 400-AIGF
1.92 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMHH
3.84 TB Solid State Drive Serial Attached SCSI (SAS) Read Intensive 12Gbps 512e 2.5in Hot-plug Drive – PM1633a 400-AQNT
RAID Option No RAID for HBA330/H330/H730/H730P (Inc Flex Bay) w/ SATADOM

780-BCCZ
Storage Controller 1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard 405-AAJU



Table. Broadwell: CPU and Memory
Component Description SKU
CPU 2 x Intel Xeon E5-2620 v4, 8-core Broadwell @2.1 GHz or higher

Various
Memory DDR4-2400, 1.2V, 16 GB, RDIMM

  • 8 x 16 GB = 128 GB
  • 16 x 16 GB = 256 GB
370-ACNX
DDR4-2400, 1.2V, 32 GB, RDIMM

  • 8 x 32 GB = 256 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
370-ACNS
DDR4-2400, 1.2V, 64 GB, LRDIMM

  • 8 x 64 GB = 512 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
370-ACNV



Table. Networking
Component Description SKU
Network Interface 1 x Network Interface
Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC 540-BBBB
Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height 540-BBCT
Dual NIC Configuration

R730xd 12 LFF Hardware Compatibility



Qualification date: July 2017



Component Description SKU
Chassis Use cases:

  • Analytics and Big Data
  • Backup and Disaster Recovery
  • Files and Objects
  • Private Cloud
  • Test and Development
  • End-User Computing/Virtual Desktop Infrastructure
PowerEdge R730xd Server

Nodes per chassis: 1

210-ADBC
2 RU Chassis with up to 12, 3.5″ Hard Drives

Nodes per chassis: 1

350-BBEU
Boot Drive 1 x 64 GB Solid State SATA-DOM Boot Drive

400-AOQL
Power Supply 2 x Hot-plug power supplyDual, Hot-plug, Redundant Power Supply (1+1), 1100W 450-ADWM
Embedded Systems Management iDRAC8 Enterprise, Integrated Dell Remote Access Controller, Enterprise 385-BBHO



Table. Storage
Component Description SKU
Storage: Hybrid Mix of SATA SSDs and HDDs
2 or 4 x 3.5″ SATA SSDs
480 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863 400-AMHB
800 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, S3610 400-AIGG
960 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863 400-AMIG
1.6 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, S3610 400-AIFO
1.92 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive 3.5in HYB CARR, SM863 400-AMIX
8 or 10 x 3.5″ HDDs
2 TB 7.2K RPM NLSAS 512n 3.5in Hot-plug Hybrid Carrier Hard Drive 400-ALPB
4 TB 7.2K RPM NLSAS 512n 3.5in Hot-plug Hybrid Carrier Hard Drive 400-ALOV
4 TB 7.2K RPM NLSAS 12Gbps 512n 3.5in Hot-plug Hard Drive 400-ALNY
8 TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Hard Drive

400-AMPP
8 TB 7.2K RPM NLSAS 12Gbps 512e 3.5in Hot-plug Drive 400-AMPG
Storage: All-Flash Only SATA SSDs
12 x 3.5″ SATA SSDs
480 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863 400-AMHB
800 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, S3610 400-AIGG
960 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, SM863 400-AMIG
1.6 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, 3.5in HYB CARR, S3610 400-AIFO
1.92 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive 3.5in HYB CARR, SM863 400-AMIX
RAID Option No RAID for HBA330/H330/H730/H730P (Inc Flex Bay) w/ SATADOM

780-BCCT
Storage Controller 1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard 405-AAJU



Table. Broadwell: CPU and Memory
Component Description SKU
CPU 2 x Intel Xeon E5-2620 v4, 8-core Broadwell @2.1 GHz or higher.

Various
Memory DDR4-2400, 1.2V, 16 GB, RDIMM

  • 8 x 16 GB = 128 GB
  • 16 x 16 GB = 256 GB
370-ACNX
DDR4-2400, 1.2V, 32 GB, RDIMM

  • 8 x 32 GB = 256 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
370-ACNS
DDR4-2400, 1.2V, 64 GB, LRDIMM

  • 8 x 64 GB = 512 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
370-ACNV



Table. Networking
Component Description SKU
Network Interface 1 x Network Interface
Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC 540-BBBB
Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height 540-BBCT
Dual NIC Configuration

R730xd 24 SFF Hardware Compatibility



Qualification date: July 2017



Component Description SKU
Chassis Use cases:

  • Analytics and Big Data
  • Database and Business Critical Apps
  • Private Cloud
  • Test and Development
  • End-User Computing/Virtual Desktop Infrastructure
PowerEdge R730xd Server

Nodes per chassis: 1

210-ADBC
2 RU Chassis with up to 24, 2.5″ Hard Drives

Nodes per chassis: 1

350-BBFD
Boot Drive 1 x 64 GB Solid State SATA-DOM Boot Drive

400-AOQL
Power Supply 2 x Hot-plug power supplyDual, Hot-plug, Redundant Power Supply (1+1), 1100W 450-ADWM
Embedded Systems Management iDRAC8 Enterprise, Integrated Dell Remote Access Controller, Enterprise 385-BBHO



Table. Storage
Component Description SKU
Storage: Hybrid Mix of SATA/SAS SSDs and HDDs
4 x 2.5″ SATA/SAS SSDs
480 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMID
800 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 400-AIFQ
960 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMHE
1.6 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 400-AIGF
1.92 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMHH
3.84 TB Solid State Drive SAS RI 12Gbps 512e 2.5in Hot-plug Drive, PM1633a 400-AQNF
20 x 2.5″ HDDs
1 TB 7.2K RPM Near-Line SAS 2.5in Hot-plug Hard Drive 400-ALUN
2 TB 7.2K RPM NLSAS 512n 2.5in Hot-plug Hard Drive 400-AMUC
Storage: All-Flash Only SATA/SAS SSDs
24 x 2.5″ SATA/SAS SSDs
480 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMID
800 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 400-AIFQ
960 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMHE
1.6 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 400-AIGF
1.92 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMHH
3.84 TB Solid State Drive SAS RI 12Gbps 512e 2.5in Hot-plug Drive, PM1633a 400-AQNF
RAID Option No RAID for HBA330/H330/H730/H730P (Inc Flex Bay) w/ SATADOM

780-BCCT
Storage Controller 1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard 405-AAJU



Table. Broadwell: CPU and Memory
Component Description SKU
CPU 2 x Intel Xeon E5-2620 v4, 8-core Broadwell @2.1 GHz or higher.

Various
Memory DDR4-2400, 1.2V, 16 GB, RDIMM

  • 8 x 16 GB = 128 GB
  • 16 x 16 GB = 256 GB
370-ACNX
DDR4-2400, 1.2V, 32 GB, RDIMM

  • 8 x 32 GB = 256 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
370-ACNS
DDR4-2400, 1.2V, 64 GB, LRDIMM

  • 8 x 64 GB = 512 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
370-ACNV



Table. Networking
Component Description SKU
Network Interface 1 x Network Interface
Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC 540-BBBB
Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height 540-BBCT
Dual NIC Configuration

R730 16 SFF Hardware Compatibility



Qualification date: July 2017



Component Description SKU
Chassis Use cases:

  • Analytics and Big Data
  • Database and Business Critical Apps
PowerEdge R730 Server

Nodes per chassis: 1

210-ACXU
2 RU Chassis with up to 16, 2.5″ Hard Drives

Nodes per chassis: 1

350-BBIL
Boot Drive 1 x 64 GB Solid State SATA-DOM Boot Drive

400-AOQL
Power Supply 2 x Hot-plug power supplyDual, Hot-plug, Redundant Power Supply (1+1), 1100W 450-ADWM
Embedded Systems Management iDRAC8 Enterprise, Integrated Dell Remote Access Controller, Enterprise 385-BBHO



Table. Storage
Component Description SKU
Storage: Hybrid Mix of SATA SSDs and HDDs
2 or 4 x 2.5″ SATA SSDs
480 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMID
800 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 400-AIFQ
960 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMHE
1.6 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 400-AIGF
1.92 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMHH
4, 6, 8, 12, or 14 x 2.5″ HDDs

1 TB 7.2K RPM Near-Line SAS 2.5in Hot-plug Hard Drive 400-ALUN
2 TB 7.2K RPM NLSAS 512n 2.5in Hot-plug Hard Drive 400-AMUC
Storage: All-Flash Only SATA SSDs
16 x 2.5″ SATA SSDs
480 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMID
800 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 400-AIFQ
960 GB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMHE
1.6 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, S3610 400-AIGF
1.92 TB Solid State Drive SATA Mix Use MLC 6Gbps 2.5in Hot-plug Drive, SM863 400-AMHH
RAID Option No RAID for HBA330 (1-16 HDDs or SSDs) SATADOM 780-BCCS
Storage Controller 1 x HBA330 12Gbps SAS HBA Controller (NON-RAID), Minicard 405-AAJU



Table. Broadwell: CPU and Memory
Component Description SKU
CPU 2 x Intel Xeon E5-2620 v4, 8-core Broadwell @2.1 GHz or higher.

Various
Memory DDR4-2400, 1.2V, 16 GB, RDIMM

  • 8 x 16 GB = 128 GB
  • 16 x 16 GB = 256 GB
370-ACNX
DDR4-2400, 1.2V, 32 GB, RDIMM

  • 8 x 32 GB = 256 GB
  • 16 x 32 GB = 512 GB
  • 24 x 32 GB = 768 GB
370-ACNS
DDR4-2400, 1.2V, 64 GB, LRDIMM

  • 8 x 64 GB = 512 GB
  • 16 x 64 GB = 1 TB
  • 24 x 64 GB = 1.5 TB
370-ACNV



Table. Networking
Component Description SKU
Network Interface 1 x Network Interface
Intel X520 Dual Port 10GbE SFP+ & i350 Dual Port 1GbE BASE-T, rNDC 540-BBBB
Intel X520 Dual Port 10GbE SFP+ Adapter, PCIe Full Height 540-BBCT
Dual NIC Configuration

Alguns segmentos que ajudamos



Manutenção de terceiros para Nutanix End-of-Life (EOL) e Nutanix End-of-Service-Life (EOSL)



A DC Parts fez uma análise em mais de 250 contratos de clientes que utilizam storage, servidores, redes e tapes e nos mostrou que 40-60% dos equipamentos desses clientes operam além das datas de término do suporte.

Existem opções simples para que você possa reduzir suas despesas e se sentir mais confiante sobre sua infraestrutura de TI. Quando você escolhe uma solução personalizada para estender a vida útil de seu equipamento de TI, pode fazer grandes economias.



Como podemos ajudar:



Oferecemos aos nossos clientes uma avaliação única para ajudar a analisar seus contratos de suporte OEM e entender exatamente quais dispositivos podem ser suportados de uma forma mais acessível, sem comprometer seu desempenho.



Suporte ao hardware Nutanix



Os serviços de suporte DC Parts fornecem suporte ao hardware Nutanix. Trabalhamos para combinar a abordagem certa com o equipamento certo para atender às suas necessidades de suporte á hardware Nutanix.

Com uma equipe altamente treinada de engenheiros certificados prontos para solucionar quaisquer problemas no hardware Nutanix, a DC Parts é exclusivamente qualificada para atendê-lo. Se desejar falar com um representante sobre a compra do suporte no hardware Nutanix, entre em contato conosco.

A DC Parts ajuda empresas de todos os tamanhos a gerenciar melhor seus data centers de TI, fornecendo serviços de suporte de terceiros para os principais fabricantes de equipamentos, incluindo: Dell, IBMHPENetapp, Oracle SunCisco e muito mais.

Com o suporte DC Parts, gerenciamos todo o seu hardware, entre os fabricantes por meio de uma ligação. O Suporte da DC Parts oferece acordos de nível de serviço flexíveis, equipes de suporte de engenharia certificadas e representantes de atendimento ao cliente dedicados.

Prolongue a vida útil e o valor de seus ativos de TI. Contate o Suporte DC Parts imediatamente.

Entre em contato com a DC Parts e vamos ajudar você otimizar melhor seu investimento em TI

Questões?

Ligue para nossa equipe de produtos em 011 3022-4694 ou envie um e-mail para: contato@dcparts.com.br

Garantia:

Todo o hardware da DC Parts é totalmente testado, garantido e vem com uma garantia de 90 dias. Acima de tudo nós iremos apoiá-lo, antes, durante e após a venda.



Experiência do produto:

Em outras palavras sabemos o quanto é importante que você obtenha o produto de que precisa seja para atender a sua necessidade. E além disso temos um time comercial atendo e uma logistica ágil para viabilizar os menores prazos de entregas possíveis.

O envio de proposta em até 2 dias úteis, experdise em data centers e integradores e sempre tentamos chegar ao melhor preço.

Não hesite em nos contatar com qualquer dúvida sobre compatibilidade, condição ou o melhor produto disponível para sua necessidade.

Nosso site representa apenas uma fração das peças que trabalhamos. Mas você pode entrar em contato com seus requisitos completos ou listas de equipamentos.

Selecione a moeda
error: Content is protected !!
Open chat
Precisa de ajuda?
